預製凝膠

Product Details

ATTO Agarose Gel for IEF

用於等電對焦(IEF)的Agarose 預製凝膠
詳細介紹

Compact (Φ7 mm x 75 mm) or Mini (Φ7 mm x 100 mm) size

用於 2D gel electrophoresis.等電對焦(IEF)的Agarose 預製凝膠

A-C agarGEL

A-C agarGEL

A-M agarGEL

A-M agarGEL

Purpose and Application 產品設計與應用
  • 2D gel electrophoresis of protein samples
  • an agarose gel for isoelectric focusing (the first dimension of 2D)
Features 產品特色
  • Two gel sizes are available

A-C type is for compact gel

A-M type is for mini gel

  • Ready to use
  • A plenty volume of protein samples can be applyed and separated.

A-C type is for ~150μg of protein

A-M type is for ~300μg of protein

  • Protein samples of high molecular weight (100 ~250 kDa) can also be separated.
  • Gel can be easily removed from the column after electrophoresis
  • High-voltage power source is unnecessary. OK with constant voltage 300V, 150-210 min.
  • Approximate separation pattern can be confirmed during fixation of the gel after electrophoresis
  • Two-dimensional electrophoresis is possible until after one month by at -20℃ storage
Specifications 產品規格
產品編號 A-C310/38/58/510 A-M310/38/58/510
產品名稱 A-C type agarGEL A-M type agarGEL
凝膠排列尺寸 Φ7 mm x 75 mm, Material: glass Φ7 mm x 100 mm, Material: glass
凝膠尺寸 Φ 2.5x50mm Φ 2.5x75mm
組成 Agarose, ampholyte, urea, etc.
pH 範圍 A-C310: 3 to 10
 A-C38: 3 to 8
A-C510: 5 to 10
A-C58: 5 to 8
A-M310: 3 to 10
A-M38: 3 to 8
A-M510: 5 to 10
A-M58: 5 to 8
樣品容量 Recommended Maximum volume: 150μg Recommended Maximum volume: 300μg
產品儲存溫度時間 Store at 5 to 10ºC for 5 months
產品包裝 10 column gels/pkg

※ The second dimension gel electrophoresis of agarGEL is suitable for the gel (PAGEL) which has a flat surface gel top without sample wells.

フラットな2次元目ゲル
1次元目ゲルを2次元目ゲルの上端にのせアガロースで接着
The second dimension gel (the front view)
Top of the gels of c-PAGEL (CD7.5/10/12.5/15/520L) and e-PAGEL (E-D7.5/10/12.5/520L) are flat without wells
The second dimension gel (the side view)
 Put agarGEL (yellow) on the top of the second dimension gel (gray), and seal it tightly with agarose (light grey).
 Grass plate of second dimension gel is shown in light blue.
